Die Casting

This is a model resin. It is superior in strength and toughness. It prints with high precision and restores the details clearly. The printed finished parts can be used for silica gel mouldturning to meet the needs of animation dolls mouldturning.

Type： E600

Color： Orange

EXP： 12 Months

Die Casting

• High detail reduction • High mechanical stability • High surface hardness

• High performance • High temperature resistant

Product Data Sheet

Liquid Properties
Appearance	Orange
Viscosity	400 cps@25℃

Mechanical Properties
Measurement	GB Method	Value
Tensile strength	GB/T 1040.1-2006	45-55 MPa
Elongation at Break	GB/T 1040.1-2006	7 %
Hardness, C.T.E.Shore D	GB/T 2411-2008	82 D
Flexural strength	GB/T 9341-2008	87 MPa
Flexural modulus	GB/T 9341-2008	2275 MPa
Izod Impact (Notched)	GB/T 1843-2008	25 J/m

Storage conditions, expiry date and transport

Store the product in the original packaging at room temperature in a dry and dark area, preferably not exceeding 25℃.

Close the packaging after each use. The expiry date of the product is mentioned on the product label. In case of exceed-

ing the expiry date, the product is no longer guaranteed in terms of treatment. Do not expose to UV-light and moisture.
